Sanyuan | SY6000 Weighing Instrument

Show 128×64 dot matrix, 7-color backlit LCD screen, English/Chinese display

Operating voltage AC220V±15%, 50/60Hz, Operating temperature-20℃~+40℃

High power consumption 15W, weight Approximately 3.4 kg

External dimensions 202×305×90mm (width×height×thickness) Opening size

Protection level IP65, button Optional 16-key English, Simplified Chinese, or Traditional Chinese keyboard layout.

Main features:

The entire unit features EMC design, strong anti-interference capability, and is suitable for industrial environments.

It adopts a high-precision, high-speed Σ-ΔA/D conversion module.

It can connect to 8 350Ω load cells.

It features automatic encryption, key encryption, key decryption, digital setting, digital calibration, and interface testing functions.

Automatic zero-tracking function is optional.

The path can be selected for the analog input of the “given flow rate” [AI: 4~20mA].

3-channel definable analog signal output for “flow rate/control current/…” [AO: 4~20mA].

It has a fast and stable closed-loop control function for batching.

3-way definable normally open switch input [DI] and 4-way definable normally open relay switch output [DO].

The start and stop of the feeder and replenisher can be controlled by the DI&DO switch.

1-channel “Accumulated High-Speed ​​Pulse” output [PO].

It can be optionally equipped with dual communication ports for connecting to external host computers, serial printers, remote monitors, remote operation stations, and wireless communication devices.

You can query and print the output per shift/day/month for a year.

The multi-tasking working mode is adopted, so the measurement and control process is not affected when performing operations such as parameter setting.

Technical Specifications:

Weighing sensor interface

Excitation voltage/high current: DC10V/250mA (8 350Ω load cells).

Signal input range: 0~25mV.

∑-△ADC: 24 bits, taking 100,000 internal codes.

Sampling frequency: 200Hz.

Zero drift: ±0.1μV/℃ RTI (referred to input).

Gain drift: ±5ppm/℃.

Nonlinearity: 0.005%FS.

Switch signal interface

3-way normally open switch input [DI].

4-channel normally open relay switch output [DO]: AC250V/DC24V, 1A.

One-channel “Accumulated High-Speed ​​Pulse” output [PO]: 100mA, DC5~24V; pulse equivalent (weight corresponding to each pulse) and pulse width are settable.

Analog signal interface

3-channel definable analog signal outputs [AO] for “flow rate/control current/…”: 4~20mA, nonlinearity: 0.05%FS; AO3: optional.

One selectable analog signal input for “given flow rate” [AI]: 4~20mA, nonlinearity: 0.05%FS.

Digital communication interface

COM1: Optional RS232/RS485/RS422/Profibus-DP/CANBUS/Ethernet modules.

COM2: RS232.

Externally connectable devices include: host computer IPC/PLC, remote monitor, remote operator station, serial printer, and wireless module.

Output power: DC5V, 100mA.

Report printing

You can query and print the output per shift/day/month for a year.
