Deskripsi
Photovoltaic Grid-Connected Inverter
Brand : SUNGROW POWER SUPPLY
| Model | SG 5KTL |
| DC side parameters | |
| Maximum DC voltage | 520Vdc |
| Starting voltage | 170V |
| Full load MPP voltage range | 260~420V |
| ***Low Voltage | 150V |
| Maximum DC power | 5500Wp |
| Maximum input current | 20A |
| Recommended PV array open circuit voltage | 400V |
| ***Number of high-power trackers/Number of strings that can be connected to each tracker | 1/3 |
| AC side parameters | |
| Rated output power | 5000W |
| Maximum output power | 5250W |
| Maximum AC output current | 25A |
| Rated grid voltage | 230Vac |
| Allowable grid voltage | 180~260Vac |
| Rated grid frequency | 50Hz/60Hz |
| Permitted grid frequency | 47~52Hz/57~62Hz |
| Total current waveform distortion rate | <3% (rated power) |
| DC current component | <0.5% (rated output current) |
| Power Factor | ≥0.99 (rated power) |
| System | |
| Maximum efficiency | 97.3% |
| European Efficiency | 96.5% |
| Protection level | IP54 (outdoor) |
| Nighttime power consumption | 0W |
| Allowable ambient temperature | -25~+60℃ |
| Cooling method | Air Cooling |
| Allowable relative humidity | 0~95%, no condensation |
| Maximum altitude allowed | 2000m |
| Display and Communication | |
| show | LCD |
| Standard communication method | RS485 |
| Optional communication method | Ethernet |
| Mechanical parameters | |
| Width x height x depth | 415x530x176mm |
| Net weight | 26kg |
Performance characteristics:
• High conversion efficiency of 97.3%
• Outdoor design (IP54) to adapt to harsh operating environments
• Multi-language LCD display interface, various operating parameters can be freely set
• Complete protection functions, higher system reliability
• High-quality aluminum appearance design, small size, light weight, easy installation
• TÜV CE certification, Italian Enel-GUIDA certification, Golden Sun certification Communication: • RS485 • Ethernet Security: • Complete protection functions: overvoltage protection, short circuit protection, island protection, overheating protection, overload protection•Compliance with standards: EN61000-6-1,EN61000-6-2,,EN61000-6-4,EN61000-3-2,EN61000-3-3EN60164-1-1,EN55022,EN50178
