SEPRI-CS-DZ Independent Overhead Dehumidification Unit

SEPRI-CS-DZ Independent Overhead Dehumidification Unit

Rp0

Price : INQUIRY
Status : PRE-ORDER
MOQ : 1 PCS
Delivery Time : 3 – 5 Weeks
Delivery Point : Warehouse Jakarta – Indonesia
Estimate Shipping Weight :  14 Kg

Stok 100

SKU: ELC/OTR/SEPRI-CS-DZ Kategori: , Tag: , Brand:

Deskripsi

Independent Overhead Dehumidification Unit

Model : SEPRI-CS-DZ

MFR : Shaanxi Sepure Electric Co., Ltd.

SEPRI-CS-DZ Standalone Top-Mounted Dehumidifier:

The SEPRI-CS-DZ top-mounted dehumidifier is   designed for use in power equipment with compact cabinet layouts, such as busbar rooms, requiring external installation and requiring automatic dehumidification and condensation prevention. It also withstands long-term use in complex electromagnetic fields and various harsh natural environments.

Product Description:

The SEPRI-CS-DZ top-mounted dehumidifier utilizes microprocessor control technology. This high-tech product is specifically developed to improve the internal humidity of power equipment, where the interior space is compact, humidity is high, and temperature fluctuations are large. Its core components include an intelligent control unit and an environmental monitoring unit. The unit automatically adjusts the ambient humidity based on site conditions, and the discharged moisture is forced to evaporate safely through an atomization unit.
Technical parameters :

Product Model Dehumidifier for busbar room
Working power supply voltage  110～264VAC, 150～370VDC (50Hz)
Rated power ≤130W
Humidity display mode 3-digit digital tube display
Temperature display mode 3-digit digital tube display
Dehumidification threshold Humidity RH=50% (default), adjustable
Dehumidification capacity 850ml/day【35℃, RH=85%】
Operating humidity range 40%～95%RH
Operating temperature range 0℃ ～ +50℃
Ambient temperature range Not lower than -20℃, not higher than 70℃
Dimensions 590mm×168mm×232mm
Drainage method Mist or drain pipe
Dehumidification volume ≤3m³
Weight About 11.75kg
Communication interface (optional) RS485

Product Features:

A thermoelectric refrigeration and dehumidification system with no moving parts and no refrigerant.No plumbing required, as condensed water is atomized and isolated for evaporation.a temperature and humidity display for fully automatic operation.A high-humidity warning function provides timely monitoring of humidity levels within the cabinet.A low-temperature dehumidification function reduces humidity and defrosts at low temperatures.
Functional Description :
The SEPRI-CS-DZ top-mounted dehumidifier utilizes microprocessor control technology and features manual and automatic switching. This unit has been improved based on comprehensive considerations to reduce user inconvenience and provide better service. The default humidity threshold is 55% RH. It also features a fault alarm display, indicating internal faults caused by fan and refrigeration component failures, wire breaks, and other factors. A green light indicates normal operation, while a fault code indicates a product malfunction.
Product Installation:
1) The intelligent control unit should be installed in a location that is consistent with site conditions and agreed upon with the user. This location should facilitate cable routing and inspection by inspection personnel, without disrupting the operation of other equipment.2) Arrangement of the environmental control unit on the busbar bridge The internal space of the busbar bridge is very compact. To ensure the insulation distance within the busbar bridge, it is installed externally on the top. The moisture in the air is condensed into water droplets through the heat exchange unit, and is isolated from the busbar bridge and discharged, and then forced to evaporate through the atomization unit.
