Steam Turbine Tripping System Input Signal Conversion Module
- Model: ETS-1
- Name: Input signal conversion module
- Control principle: open loop
- Processing customization: non-processing customization
- Application: ETS output
- Range: 8 channels
- Dimensions: 151×87×40mm
- Brand: Jiangyin Zhonghe
Technical Parameters: (input module):
Input signal: 8-way switch input signal (field signal)
Output signal: 16-way switch quantity (redundant input signal)
Dimensions: 151×87×40
Technical parameters: (output module):
Input signal: 2 channels and 8 channels of switch input and output signals (from PLC, a total of 16 channels)
Output signal: redundant 8-way switch quantity (to load)
Dimensions: 151×87×40
ETS power supply filter (ETS-2 type)
Technical parameters:
Input power: three-way AC220V, 5A
Output power: three-way AC220V, 5A (after filtering)
Dimensions: 101×87×63
ETS DC power automatic switching module (ETS-3 type)
Technical parameters:
Input power: four-way DC24V, 5A
Output power: two DC24V, 5A (redundant)
Dimensions: 101×87×63
