Control Board
The Hengchun CKD-Y-PT-30-6 Control Board is an OEM spare part for Hengchun CKD series electric actuators, manufactured by Yangzhou Hengchun Electronics Co., Ltd.
Applications:
• Valve automation in oil & gas pipelines, refineries, and chemical plants
• Power generation (thermal, hydro, nuclear)
• Water treatment and wastewater facilities
• Hazardous area instrumentation requiring explosion-proof actuators
- Type: Electric actuator control PCB
- Model: CKD-Y-PT-30-6
- Compatible : CKD series electric actuators.
- Function: Provides motor control, power regulation, and bus communication interface for CKD series actuators used in valve automation and industrial process control.
- Power Supply: 220V single-phase / 380–690V three-phase AC, 50/60 Hz
- Torque Range (Actuator): 1 kN·m – 100 kN·m (depending on actuator model)
- Motor Speed: 8–192 rpm (customizable)
- Protection Grade: IP68 (dust-tight and waterproof)
- Explosion-Proof Options: Exd II BT4 / CT4 / CT6
- Operating Temperature: -30 °C to +70 °C (standard), up to 125 °C (custom)
- Motor Insulation: Class F (Class H optional)
- Communication Options: Modbus, Profibus, Foundation Fieldbus (FF bus)
- PCB Features: Relays, capacitors, connectors, transformer interface for actuator motor drive
- Dimensions: Approx. 150–200 mm × 100–120 mm (fits actuator housing)
- Weight: ~200–300 g (PCB only)
- Shape: Rectangular PCB with relays, capacitors, connectors, and transformer interface
- MFR : YANGZHOU HENGCHUN ELECTRONICS
