Square Oil Level Thermostat
BWY-806 series oil level temperature controller uses a new generation of “multi-turn spring tube” as the driving element, the instrument greatly improves the temperature measurement accuracy and service life. All stainless steel material gram body can effectively protect the internal components from environmental impact and dirt invasion.
Technical parameters:
I. Execution standard: JB/T 6302-2016
II. Ambient temperature:-50℃-+55℃
III. Range:0~160℃
IV. Protection class : IP65
V. Indication accuracy : 1.5 grade
VI. Setting accuracy: ±2℃
VII. Dial graduation value: 2℃
VIII. Return value of travel switch: ≤8℃
IX. Insulation withstand voltage: between contacts and contact to ground, 2kV/1min
X. Contact capacity: AC 250V/5A
XI. Factory temperature design value: K1 = 50℃, K2 = 60℃, K3 = 75℃, K4 = 95℃, K5 = 115℃, K6 = 125℃.
XII. Junction box: Terminal should be able to access 2.5mm^2 cable.
XIII. Outlet hole thread:3*M25*1.5
XIV. Conforms to the transmitter:φ140mm*333mm
XV. Overall dimensions:Head 132mm*290mm*100mm
XVI. Shell color and material: Stainless steel natural color
XVII. Fastener material: stainless steel A4-70
XVIII. Capillary material: stainless steel, plus stainless steel jacket
XIX. Temperature package material: stainless steel 304
Product Model:
|
Model |
Capillary length/m | Dial Output Signal | Type | Warm pack form |
| BWY-806 | 6 | / | compact | Simple Warm Bag |
| BWY-806A | 6 | 1*PT100 | ||
| BWY-806AA | 6 | 2*PT100 | ||
| BWY-806D | 6 | 1*4~20mA | ||
| BWY-806DD | 6 | 2*4~20mA | ||
| BWY-806AD | 6 | 1*PT100+1*4~20mA | ||
| BWY-806F | 6 | / | Combination | Used in conjunction with the PT-F15 transmitter |
Note：Capillary length (generally 6m,9m,12m), others can be ordered by need.
