High Voltage Damping Resistance
Model : ZG12-1800W/500Ω
Product Name : Damping Resistor
Material : Corundum shaft
Unit Weight : 3 kg
Scope of application : Dust Collector
High-voltage silicon rectifier power supplies for electrostatic precipitators, which are equipped with high-voltage damping resistors and are compatible with GGAJ02 type electrostatic precipitators and various specifications of high-voltage dust removal isolation switch control cabinets and high-voltage inputs from environmental protection manufacturers across the country.
Commonly used high-voltage silicon rectifier power supplies with high-voltage damping resistors:
Dimensions and Specifications:
|
Serial Number |
Matching porcelain bottle specifications and dimensions |
|
I Damping Resistor |
Corundum porcelain bottle Φ75mm×210mm (length)×M18 (M16, M14, M12) |
|
II Damping Resistor |
Corundum porcelain bottle Φ98mm×210mm (length)×M18 (M16, M14, M12) |
|
III Damping Resistor |
Corundum porcelain bottle Φ130mm×210mm (length)×M18 (M16, M14, M12) |
|
IV Damping Resistor |
Corundum porcelain bottle Φ98mm×225mm (length)×M18 (M16, M14, M12) |
|
V Damping Resistor |
Corundum porcelain bottle Φ98mm×300mm (length)×M18 (M16, M14, M12) |
|
VI Damping Resistor |
Corundum porcelain bottle Φ75mm×380mm (length)×M18 (M16, M14, M12) |
|
VII Damping Resistor |
Corundum porcelain bottle Φ98mm×380mm (length)×M18 (M16, M14, M12) |
|
resistance wire |
Φ0.25mm～Φ0.65mm |
