Compact Self‑Monitoring Flame Monitor
DURAG D‑LX 100UA‑G1/M2/0000/PP2 is a compact, self‑monitoring flame monitor from the D‑LX 100 series, designed for fail‑safe flame detection in industrial combustion systems. It integrates the flame sensor and control electronics in one housing, reducing cabinet space and simplifying installation.
DURAG D‑LX 100UA‑G1/M2/0000/PP2:
Type / Model / Part Number:
- Type: Compact Flame Monitor (self‑contained flame detector)
- Model: D‑LX 100UA‑G1/M2/0000/PP2
- Part Number: D‑LX 100UA‑G1/M2/0000/PP2
- Series: D‑LX 100
- Brand: DURAG
- Manufacturer: DURAG Group GmbH
Product Overview:
The D‑LX 100UA is a fail‑safe flame monitor for gas, oil, and coal flames. It uses UV, VIS, or IR flame sensors (depending on variant) and provides a 0/4–20 mA flame signal output. The UA version is universal analog, while the suffix PP2 indicates a specific output and configuration package. It is suitable for continuous or intermittent operation and is ATEX‑approved for hazardous areas.
Specifications:
| Feature | Specification |
|---|---|
| Detection Range | UV, VIS, or IR (variant dependent) |
| Power Supply | 24 V DC ±10% |
| Power Consumption | ~5 W |
| Output Signal | 0/4–20 mA (analog), PP2 configuration |
| Operation | Continuous or intermittent |
| Self‑Monitoring | Yes, fail‑safe with automatic fault detection |
| Certifications | ATEX Zone 1/2, IECEx, SIL3, CE, UL, FM |
| Protection Class | IP65 (aluminum housing) |
| Operating Temp. | −40 °C … +85 °C |
| Mounting | Direct or via DURAG fibre optic system (D‑LL 7xx) |
Dimensions & Weight:
- Dimensions: ~180 × 80 × 80 mm
- Weight: ~1.5 – 2.0 kg
Applications:
- Power stations and steam generators
- Refineries and petrochemical plants
- Cement and steel industry kilns
- Waste incinerators
- Hazardous area combustion systems (Zone 1/2)
