Deskripsi
Soot Blowing Spindle V04 Sootblower Spindle V04-2-1-0, V04 and V92 furnace sootblowers
- Brand: Hubei Deleman Environmental Protection Equipment Co., Ltd.
- Model: Sootblower spindle V04-2-1-0
- Application : Used for purging the water-cooled wall area of the boiler furnace
- Processing customization: non-processing customization
Product Overview:
The V04 sootblower spindle is a key component in short retractable sootblowers used in boiler furnaces. It drives the nozzle head forward and backward during sootblowing, ensuring effective cleaning of furnace water‑cooled walls. The spindle’s helical design allows precise motion transfer from the motor gearbox to the nozzle assembly.
Specifications:
| Feature | Specification |
|---|---|
| Blowing Medium | Steam |
| Steam Temperature | Up to 500 °C |
| Operating Pressure | 0.8–1.5 MPa |
| Travel Distance | 255–300 mm |
| Blowing Time | 11–60 seconds |
| Steam Consumption | 60–110 kg/min |
| Blowing Angle | 30–360° |
| Valve Body Material | Cr‑Mo alloy steel |
| Nozzle Material | Heat‑resistant stainless steel |
| Estimated Weight | ~15 kg |
Dimensions:
- Length: ~300–400 mm
- Diameter: ~80–100 mm
- Weight: ~15 kg
Applications:
- Boiler sootblower systems
- Power plants (coal, biomass, waste‑to‑energy)
- Cement kilns and industrial furnaces
- Heat exchanger cleaning
