Deskripsi
High-End MPPT (Maximum Power Point Tracking) Controller
Model : SC-MH 20A
Brand : SCPOWER
OEM : SHANGCHI POWER TECHNOLOGY
SC-MH series ranks first in the world’s maximum power point tracking (MPPT) solar charge controller. It has the advantages of high conversion rate, high stability, wide PV voltage range input, can charge a variety of batteries, professional host computer monitoring software, etc. It is currently the most advanced solar charge controller.
Features:
- Conversion efficiency up to 99%
- Intelligent design, online upgrade, customers enjoy lifetime upgrade service
- Adopt brand components with high temperature resistance not less than 105℃ and design life of more than 10 years
- PV wide voltage range input, the system maximum DC input voltage is 420V
- Customers can choose to charge 4 types of commonly used batteries, and can customize charging for other types of batteries
- RS232 communication, supporting host computer software, can be extended to LAN remote control
- LED display, host computer software displays various parameters
- Products have passed CE, ISO9001 certification
- One-year warranty
Product parameters:
| SC-MH MPPT Solar Controller High-End Series | ||||
| SC-MH High-end Series | 20A | 25A | 30A | |
| Charging Mode | MPPT automatic maximum power point tracking | |||
| Charging method | Three stages: constant current (MPPT), constant voltage, floating charge | |||
| Overall efficiency | 96V/120V/192V/ 240V System |
≥98% | ||
| Input Parameters | ||||
| MPPT operating voltage range |
96V System | DC110V – DC220V | ||
| 120V System | DC140V – DC260V | |||
| 192V System | DC220V – DC360V | |||
| 240V System | DC300V – DC380V | |||
| Low voltage input protection point |
96V System | 115V | ||
| 120V System | 145V | |||
| 192V System | 225V | |||
| 240V System | 295V | |||
| Low voltage input recovery point |
96V System | 120V | ||
| 120V System | 150V | |||
| 192V System | 230V | |||
| 240V System | 300V | |||
| High voltage input protection point |
96V/120V/192V/ 240V System |
290V/290V/430V/430V | ||
| High voltage input recovery point |
96V/120V/192V/ 240V System |
280V/280V/420V/420V | ||
| Maximum solar input voltage |
96V System | 280V | ||
| 120V System | 280V | |||
| 192V System | 420V | |||
| 240V System | 420V | |||
| Maximum solar panel input power |
96V System | 2240W | 2750W | 3300W |
| 120V System | 2760W | 3450W | 4140W | |
| 192V System | 4400W | 5500W | 6600W | |
| 240V System | 5520W | 6900W | 8200W | |
| Charging parameters | ||||
| Available battery types |
96V/120V/192V/ 240V System |
Sealed lead-acid battery, discharged battery, gel battery, nickel-cadmium battery (can be customized to charge other types of batteries) |
||
| Rated charging current |
96V/120V/192V/ 240V System |
20A | 25A | 30A |
| Packing size: Length x Width x Height (mm) | 155*308*86 | |||
| Net Weight(kgs) | 5 | |||
| Note: The above are basic parameters, please refer to the specification or manual for details. | ||||
